Non-Insulated Brazed Seam Tinned Lug

$2.890 - $318.250
SKU:
TL8
Grand Total:
2.89
Add to Custom Catalog

Related Products

Product Description


Wire Size Stud Size Stud Opening Length Tab Width
8 AWG #10 0.198" 0.98" 0.38"
8 AWG 1/4" 0.265" 0.98" 0.38"
8 AWG 3/8" 0.390" 0.98" 0.38"
8 AWG 5/16" 0.328" 0.98" 0.38"
8 AWG 1/2" 0.515" 0.98" 0.38"
6 AWG #10 0.198" 1.18" 0.49"
6 AWG 1/4" 0.265" 1.18" 0.49"
6 AWG 3/8" 0.390" 1.18" 0.49"
6 AWG 5/16" 0.328" 1.18" 0.49"
6 AWG 1/2" 0.515" 1.18" 0.49"
4 AWG #10 0.198" 1.28" 0.47"
4 AWG 1/4" 0.265" 1.28" 0.47"
4 AWG 3/8" 0.328" 1.28" 0.47"
4 AWG 5/16" 0.390" 1.28" 0.47"
4 AWG 1/2" 0.515" 1.28" 0.47"
2 AWG #10 0.198" 1.58" 0.65"
2 AWG 1/4" 0.265" 1.58" 0.65"
Wire Size Stud Size Stud Opening Length Tab Width
2 AWG 3/8" 0.328" 1.58" 0.65"
2 AWG 5/16" 0.390" 1.58" 0.65"
2 AWG 1/2" 0.453" 1.58" 0.65"
1/0 AWG 1/4" 0.265" 1.95" 0.90"
1/0 AWG 3/8" 0.390" 1.95" 0.90"
1/0 AWG 5/16" 0.328" 1.95" 0.90"
1/0 AWG 1/2" 0.515" 1.95" 0.90"
2/0 AWG 1/4" 0.265" 2.02" 0.95"
2/0 AWG 3/8" 0.390" 2.02" 0.95"
2/0 AWG 5/16" 0.328" 2.02" 0.95"
2/0 AWG 1/2" 0.515" 2.02" 0.95"
3/0 AWG 3/8" 0.390" 2.15" 1.06"
3/0 AWG 5/16" 0.328" 2.15" 1.06"
3/0 AWG 1/2" 0.515" 2.15" 1.06"
4/0 AWG 1/4" 0.265" 2.42" 1.10"
4/0 AWG 3/8" 0.390" 2.42" 1.10"
4/0 AWG 1/2" 0.515" 2.42" 1.10"




Non-insulated brazed seam tinned lugs create long-lasting, durable electrical connections. These lugs come in a variety of gauge sizes and stud sizes to handle nearly any task. Pacer offers non-insulated brazed seam tinned lugs in 8 AWG to 4/0 AWG. The available stud sizes include; #10, 1/4", 5/16", 3/8" and 1/2". These lugs are made from copper that has been tinned to provide excellent protection. In this way, they are already corrosion resistant making one less thing you have to worry about. This makes them perfect for use in marine environment. To use non-insulated brazed seam tinned lugs simply strip your cable to the proper length. Slide the lug over the cable with the conductor extending just past the opening. Crimp with the proper tool and you're done. Selecting the correct non-insulated brazed seam lug isn't always an easy task. Contact a Pacer expert today with any questions that you may have.

Features:

  • Tin Plated
  • Silver alloy brazed seams

Compliances:

  • E.T.P. (Electrolytic Tough Pitch) CDA-110
  • ASTm-B-152 copper rated at 100% conductivity
  • UL & CSA Approved
  • RoHS Compliant
