What are Deutsch Accessories?
Deutsch Accessories are any of a number of parts that work with Deutsch connectors and terminals to enhance their functionality or longevity. These can include Deutsch series boots, cavity plugs, or contact removal tools. The best part of these accessories is that they can only serve to enhance an already potent electrical connection. This means that by utilizing Deutsch accessories, you can get more out of your electrical system. Now that you know what Deutsch accessories are, let’s take a look at what makes each of these accessories different and where you might use them.
"The best part of these accessories is that they can only serve to enhance an already potent electrical connection."
Where are these products implemented?
Deutsch accessories are extremely simple to use
Deutsch accessories are implemented in applications where Deutsch connectors need something extra to fit the needs of a given application. Basically, when the connection needs a higher-level of protection from the elements than normal. These are the perfect choice when replacing existing connectors. If you have cracked connectors, burnt connectors, or otherwise damaged connectors, then these may be part of the replacement set you're looking for. Just remember you will likely need the proper tools and connectors. Now that we've covered the basics, let us look at what protections these connectors offer.
What is the difference between Deutsch Accessories?
The difference between Deutsch accessories is found in their intended uses and applications as well as their level of enhanced functionality for Deutsch products. Each of these accessories is designed specifically for use with a certain aspect of the Deutsch environmentally sealed connector installation process. Below let’s take a look at each of these Deutsch accessories individually.
Deutsch Boots
Cavity Plugs
Removal Tool
What are Deutsch Boots?
Deutsch boots are a line of protective covers built for use with the DT series line of connectors. They are designed to slide over the wire and then be pulled over the assembled connection point. In this way, they offer an additional layer of protection from moisture, dirt, dust, and other environmental hazards including abrasion and impact. They are enclosed and offer Ingress Protection of IP68 and IP6K9K. For more on what Ingress protection ratings mean, click HERE. DT series boots are used by some of the biggest boat builders and can protect electrical connections in the toughest of environments. From their simple installation to their long-lasting design, these are the boots you need for that extra protection.
Where would I use Deutsch cavity plugs?
Deutsch cavity plugs are designed for use with Deutsch connectors when there are open cavities not filled by contacts. This is important as they offer an additional layer of protection from environmental hazards such as moisture, dirt, dust, and more. Sounds similar to the boots above, doesn’t it? The main difference is that the boots go outside of the connection point and the cavity plugs go inside the connection point. We cannot recommend these enough. They ensure that your electrical connections require less maintenance and last longer than they would without cavity plugs. These cavity plugs offer field serviceability and a smooth installation process.
How do I use Deutsch contact removal tools?
Using Deutsch contact removal tools is a surprisingly simple process that starts with finding the correct size contact removal tool for the intended wire. Once you have the correct removal tool, the next step is to slide the central tube of the tool over the wire itself. Now, with the wedge-lock out of the way, simply push the removal tool towards the connector body with gentle force. Upon breaching the entrance of the connector body continue to apply gentle pressure while working the tool in a circular motion. Continue this process until you feel the interior lock of the connector body release. At this point, hold the tool in place and gently pull on the wire until it comes out of the connector body. If at any point the wire stops, reapply pressure to the tool and continue to work in a circular motion until you feel the lock give away a second time.
How do Deutsch accessories help?
Deutsch accessories help by allowing you to perform tasks that would otherwise be impossible. Imagine trying to use a connector that will be exposed to heavy weather without a protective boot. I think we can agree that the connection would ultimately be compromised. The same idea works for the removal tool and the cavity plugs. They offer you abilities you simply would not have otherwise. In this way, they help you by allowing you to complete tasks and protect equipment in ways that serve a functional purpose.
What products do Deutsch accessories work with?
Deutsch accessories are designed to work with Deutsch connectors, contact, pins, and sockets. The Deutsch boots are for use with the connector bodies as are the cavity plugs. The contact removal tool is for use with the connector bodies as well as the Deutsch pins and sockets. Each of these accessories is built for repeated use and is ideal for field service. To see our line of connector bodies or Deutsch pins and sockets, simply click on the corresponding image below to be taken to that particular section of the site.
