1/0 AWG, Battery Cable Assemblies, Red

$11.290 - $57.540
SKU:
B10R
Custom Product: This product is made to order, and cannot be returned or refunded. Please allow extra time for processing.
Grand Total:
11.29

Frequently Bought Together

Please choose Options for all selected Products

  • Choose Options

Product Description

*This Page was Updated on 12/21/2020.




AWG 1/0
Cond. Stranding 19x56/0.0100
Nom. Ins. Thickness 0.080
Nom. O.D. 0.600
Nom. Circular Mils 106400
Nom. MM2 53.9

Compliances:

CABLES:

  • UL Standard 1426 BC-5W2
  • AWM 1232/1284
  • MTW, CSA: TEW
  • ABYC: E-11.16
  • Coast Guard: 33 CFR part 183 Subpart 1

CRIMPS:

  • Exceed UL 486 and MIL-T-7928



Characteristics:

  • Conductor: Annealed fine stranded tinned copper ASTM B172 Class K
  • Insulation: -20 °C to 105 °C Flexible color coded PVC
  • Temperature Rating: 105 °C Dry, 75 °C Wet, 60 °C Oil
  • Voltage Rating: 600-V
  • Resistant to: Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture

All of Pacer Group's 1/0 AWG Red Battery Cable Assemblies are custom manufactured in Sarasota, FL USA. They are built using Pacer Group's own UL approved marine cable. How is it that they are manufactured? Well, it starts by using a precision cut and strip machine. The machine is designed for repeatable and accurate cuts. After the cable is cut to the proper length, terminals are added to each end. Pacer Group utilizes a hydraulic-pneumatic crimper that creates an unbeatable gas tight crimp. After the terminals are crimped, heat shrink is added to the assembly. This epoxy-lined heat shrink creates a barrier which makes a moisture and airtight connection.

This process is designed to create superior 1/0 AWG red battery cable assemblies. The assemblies are so well built that they will likely outlive the battery itself. Pacer Group perfected this process with the boater in mind. 1/0 AWG red battery cable assemblies are easy to bend and route and offer excellent durability and flexibility. They are designed to withstand the harshest marine conditions. They are resistant to Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture. Contact a Pacer Group expert today with any questions that you may have.

Features:

  • Pacer UL Approved Battery Cable (Type III Stranded Tinned Copper)
  • Epoxy Lined Heat Shrink
  • Custom Lengths and Configurations Available
  • Easy to bend and route
  • Excellent flexibility with the durable properties of PVC

Print:

  • PACER E157097 (UL)1/0AWG 600V BC-5W2 105°C DRY, 75° WET OR MTW OR AWM 1232/1284 VW-1 OIL RESISTANT 1 LL102583 CSA TEW 105°C FT1
