Shielded Multiconductor Cable, 16 AWG

$1.080 - $5.370
SKU:
M16/
Minimum Purchase: 25
Feet
Grand Total:
1.08

Frequently Bought Together

Please choose Options for all selected Products

  • Choose Options

Product Description

Cable Specifications See Table
AWG  16
Conductor Stranding  19/0.0117
Nom. Insulation Thickness 2 Conductor @ 0.013
3 Conductor @ 0.013
4 Conductor @ 0.016
6 Conductor @ 0.016
8 Conductor @ 0.016
Nom. Jacket Thickness  2 Conductor @ 0.037
3 Conductor @ 0.037
4 Conductor @ 0.032
6 Conductor @ 0.032
8 Conductor @ 0.032
Nom. O.D.

2 Conductor @ 0.243
3 Conductor @ 0.255
4 Conductor @ 0.290
6 Conductor @ 0.350
8 Conductor @ 0.380




Shielded multiconductor 16 AWG cables are used for a wide range of purposes. Oftentimes, you will find them in things like consumer electronics and industrial control equipment. They are also used in advanced signal transmissions in controlled environments. What does all that mean? Well, it simply means that shielded multiconductor 16 AWG cables are utilized for controlling equipment. By using 16 AWG shielded multiconductor cable you have the option of selecting between 2 to 8 conductors.

What benefit is there from using shielded multiconductor cables? In most industrial facilities, there is a lot going on. What I mean is there are many pieces of equipment with a lot of wires in them, all running through a given facility. This can create EMI (electromagnetic interference) also named RFI (radio frequency interference). EMI/RFI has the potential to greatly reduce the performance of a circuit. In certain cases, it can even stop the circuit from functioning. This is why you would want to make sure to utilize shielded multiconductor 16 AWG cable. The shielding in this type of cable works in two ways. For starters, it has the ability to reflect a lot of energy. This serves to prevent the energy from interrupting the circuit. Next, the shielding can conduct much of that energy to the ground. Together, these actions ensure that the EMI/RFI does not reach the conductors.

These cables are built to meet the requirements for UL, CSA and NEC. Temperatures and voltages are not always the exact same from cable to cable. Call a Pacer Group expert for specifications on multiconductor cable.

Features:

  • 100% Flexfoil aluminium/polyester foil facing out
  • Stranded tinned copper drain wire
  • Fully annealed stranded tinned copper per ASTM B-33
  • Premium grade color coded PVC insulation
  • Grey PVC jacket

Compliances:

  • Coast Guard, NMMA, & ABYC Standards
  • NEC Article 800 Type CM (UL: 75°C)
  • UL Style 2464 ( UL: 80°C, 300 V, VW-1 )
  • CSA CMG (CSA: 60°C)
  • CE: Low Votage Directive (LVD 2006/95/EC)
  • RoHS compliant directive 2011/65/EC
  • Vertical tray cable flame test per UL1581 and IEEE 383 (70,000 BTU)

Applications:

  • Consumer electronics
  • Industrial process control equipment
  • Suitable for EIA RS-232 applications
  • Advanced signal transmission in controlled environments
