Shielded Multi conductor Cable, 22 AWG

$0.430 - $1.920
SKU:
M22/
Minimum Purchase: 25
feet
Grand Total:
0.43

Frequently Bought Together

Please choose Options for all selected Products

  • Choose Options

Product Description

Cable Specifications See Table
AWG  22
Conductor Stranding  7/30
Nom. Insulation Thickness 2 Conductor @ 0.010"
3 Conductor @ 0.010"
4 Conductor @ 0.010"
6 Conductor @ 0.010"
8 Conductor @ 0.010"
10 Conductor @ 0.010"
15 Conductor @ 0.010 "
Nom. Jacket Thickness  2 Conductor @ 0.032"
3 Conductor @ 0.032"
4 Conductor @ 0.032"
6 Conductor @ 0.032"
8 Conductor @ 0.032"
10 Conductor @ 0.032"
15 Conductor @ 0.032"
Nom. O.D.

2 Conductor @ 0.169"
3 Conductor @ 0.177"
4 Conductor @ 0.190"
6 Conductor @ 0.219"
8 Conductor @ 0.235"
10 Conductor @ 0.269"
15 Conductor @ 0.304"



Compliances:

  • NEC Article 800 Type CM (UL: 75°C)
  • UL Style 2464 ( UL: 80°C, 300 V, VW-1 )
  • CSA CMG (CSA: 60°C)
  • CE: Low Votage Directive (LVD 2006/95/EC)
  • RoHS compliant directive 2011/65/EC
  • Vertical tray cable flame test per UL1581 and IEEE 383 (70,000 BTU)

Shielded multi conductor cables are used for a variety of purposes. These include things like consumer electronics and industrial process control equipment. They are also used in advanced signal transmissions in controlled environments. What does all of that mean? Well, it basically means that shielded multi conductor 22 AWG cable is used for controlling equipment. By using shielded multi conductor cable you are given the option of selecting between 2 to 15 conductors.

Why use shielded multi conductor 22 AWG cable? In many industrial environments, there is a lot going on. What I mean is that there is usually a lot of equipment with a multitude of wires in a given facility. This can lead to EMI (electromagnetic interference) often called RFI (radio frequency interference). EMI/RFI can reduce the performance of a circuit. In some cases, it can even stop the circuit from functioning. This is where shielded multi conductor 22 AWG cable comes in. The shielding works in two different ways. First, the shield can actually reflect a lot of the energy. This prevents it from interrupting the circuit. Second, the shielding can help to conduct some of that energy to the ground. Both of these actions make sure that the EMI/RFI does not reach the conductors.

These cables meet the current requirements for UL, CSA, and NEC. Temperatures and voltages may not be the same from cable to cable. Call a Pacer Group expert for specifications on the cable you need.

Features:

  • 100% Flexfoil aluminium/polyester foil facing out
  • Stranded tinned copper drain wire
  • Fully annealed stranded tinned copper per ASTM B-33
  • Premium grade color coded PVC insulation
  • Grey PVC jacket

Applications:

  • Consumer electronics
  • Industrial process control equipment
  • Suitable for EIA RS-232 applications
  • Advanced signal transmission in controlled environments
