3-to-1 Adhesive Lined Heat Shrink 1' Lengths
$1.750 - $10.125
- SKU:
- BEHS-
Related Products
Product Description
| Part Number | Expanded I.D. | Recovered I.D. | Wire AWG | Recovered Wall Thickness | Available Colors |
| BEHS-1/8 | 0.125" | 0.0400" | 20, 18 | 0.040" | BK, CL, RD |
| BEHS-3/16 | 0.188" | 0.0600" | 16, 14 | 0.040" | BK, CL, RD, YL |
| BEHS-1/4 | 0.250" | 0.0800" | 12, 10 | 0.040" | BK, CL, GN, WH, RD, YL |
| BEHS-3/8 | 0.375" | 0.1250" | 8, 6 | 0.060" | BK, CL, GN, WH, RD, YL |
| BEHS-1/2 | 0.500" | 0.1600" | 4, 2 | 0.070" | BK, CL, GN, WH, RD, YL |
| BEHS-3/4 | 0.750" | 0.2500" | 1, 1/0, 2/0 | 0.070" | BK, CL, GN, WH, RD, YL |
| BEHS-1 | 1.000" | 0.3200" | 3/0, 4/0 | 0.100" | BK, CL, GN, WH, RD, YL |
| BEHS-1.5 | 1.500" | 0.5100" | N/A | 0.100" | BK, RD |
| BEHS-2.05 | 2.050" | 0.8000" | N/A | 0.100" | BK |
Three to one heat shrink is a flexible, cross linked polyolefin tube which possesses a melt-able inner lining of adhesive that flows when heated to ensure complete sealing.
In addition to insulation and mechanical protection, this heat shrink tubing provides a moisture proof seal for encapsulation of wires, splices, breakouts and components. Have a question about heat shrink or any other Pacer product? Contact a Pacer expert today.
APPLICATIONS:
- Environment/moisture protection
- Sealing electrical connections
- Encapsulate splices
- Sealing cable ends
- Strain relief
- Rugged abrasion/vibration protection
- Clear heat shrink is ideal for labeling
CHARACTERISTICS:
- Operating Temperature: -55°C to 110°C
COMPLIANCES:
- MIL-I-23053/4 Class 3
- RoHS
FEATURES:
- A flame-retardant tubing (except clear) with an internal layer of thermo-plastic adhesive which provides a barrier against contaminants.
- Still highly flexible for conforming to irregular shapes.
- Environmental protection for electronic components.
- Protection of automobile, marine and truck wire splices and harness breakouts.
- Adhesive-lining provides a barrier against contaminants.
- Excellent resistance to acids and alkalis.
- Good resistance to fuel, oil and solvents.
