12 Gauge Marine Wire

$0.477 - $0.478
SKU:
WUL12
Minimum Purchase: 25
feet
Grand Total:
0.477

Videos Hide Videos Show Videos

Frequently Bought Together

Please choose Options for all selected Products

  • Choose Options

Product Description


12 AWG UL Primary Wire

Wire Specifications See Table
AWG 12
Conductor Stranding 65/0.0100
Nom. Insulation 0.032
Nom. O.D. 0.160
Nom. Circular Mils 6500
Approx LB/M 32.0




Pacer's 12 AWG UL-approved marine wire is manufactured to withstand harsh marine environments. It is designed to meet and exceed extremely stringent specifications. This 12 AWG marine wire is built in-house in Sarasota FL, USA to ensure the absolute highest level of quality. This cable is constructed from Type III class K tinned copper. It offers superb durability and flexibility. The tinned copper conductors resist corrosion and add to the life of the wire. What type of insulation is used? Well, after the copper is tinned, the following step is to insulate it with a flexible PVC jacket. This insulation is designed to protect the wire and makes it resistant to a multitude of hazards. These hazards include; alkali, abrasion, acid, gas, oil, flame, and moisture. What standards and compliances does Pacer Group's wire meet? This marine wire exceeds the standards and requirements of ABYC, NMMA, and UL.

Features:

  • Stranded, tinned copper conductors
  • Highly flexible color-coded insulation

Compliances:

  • UL Standard 1426 BC-5W2
  • ABYC: E-11.14
  • UL: MTW
  • Coast Guard: 33 CFR 183.401 Subpart 1-Electrical Systems
  • Temperature Rating: 105 °C Dry, 75 °C Wet

Characteristics:

  • Conductor: Type III annealed finely stranded tinned copper ASTM B172 Class K
  • Insulation: -20 °C to 105 °C Flexible, Color Coded PVC
  • Voltage Rating: 600-V
  • Resistant to: Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture

Print:

  • (For 18-8 AWG) PACER E157097 (UL)_AWG 600V BC-5W2 105°C DRY, 75° WET OR MTW OR AWM 1015/1230 (1028/1231 -8AWG ONLY) VW-1 OIL RESISTANT I

Applications:

  • Point to point wiring
  • Internal wiring of panels and motors
